-->Conformance
Version Introduced: ODBC 1.0 Standards Compliance: ODBC
Summary
SQLForeignKeys can return:
A list of foreign keys in the specified table (columns in the specified table that refer to primary keys in other tables).
A list of foreign keys in other tables that refer to the primary key in the specified table.
The driver returns each list as a result set on the specified statement.
Syntax
Arguments
StatementHandle
[Input] Statement handle.
PKCatalogName
[Input] Primary key table catalog name. If a driver supports catalogs for some tables but not for others, such as when the driver retrieves data from different DBMSs, an empty string (') denotes those tables that do not have catalogs. PKCatalogName cannot contain a string search pattern.
If the SQL_ATTR_METADATA_ID statement attribute is set to SQL_TRUE, PKCatalogName is treated as an identifier and its case is not significant. If it is SQL_FALSE, PKCatalogName is an ordinary argument; it is treated literally, and its case is significant. For more information, see Arguments in Catalog Functions.
NameLength1
[Input] Length of *PKCatalogName, in characters.
PKSchemaName
[Input] Primary key table schema name. If a driver supports schemas for some tables but not for others, such as when the driver retrieves data from different DBMSs, an empty string (') denotes those tables that do not have schemas. PKSchemaName cannot contain a string search pattern.
If the SQL_ATTR_METADATA_ID statement attribute is set to SQL_TRUE, PKSchemaName is treated as an identifier and its case is not significant. If it is SQL_FALSE, PKSchemaName is an ordinary argument; it is treated literally, and its case is significant.
NameLength2
[Input] Length of *PKSchemaName, in characters.
PKTableName
[Input] Primary key table name. PKTableName cannot contain a string search pattern.
If the SQL_ATTR_METADATA_ID statement attribute is set to SQL_TRUE, PKTableName is treated as an identifier and its case is not significant. If it is SQL_FALSE, PKTableName is an ordinary argument; it is treated literally, and its case is significant.
NameLength3
[Input] Length of *PKTableName, in characters.
FKCatalogName
[Input] Foreign key table catalog name. If a driver supports catalogs for some tables but not for others, such as when the driver retrieves data from different DBMSs, an empty string (') denotes those tables that do not have catalogs. FKCatalogName cannot contain a string search pattern.
If the SQL_ATTR_METADATA_ID statement attribute is set to SQL_TRUE, FKCatalogName is treated as an identifier and its case is not significant. If it is SQL_FALSE, FKCatalogName is an ordinary argument; it is treated literally, and its case is significant.
NameLength4
[Input] Length of *FKCatalogName, in characters.
FKSchemaName
[Input] Foreign key table schema name. If a driver supports schemas for some tables but not for others, such as when the driver retrieves data from different DBMSs, an empty string (') denotes those tables that do not have schemas. FKSchemaName cannot contain a string search pattern.
If the SQL_ATTR_METADATA_ID statement attribute is set to SQL_TRUE, FKSchemaName is treated as an identifier and its case is not significant. If it is SQL_FALSE, FKSchemaName is an ordinary argument; it is treated literally, and its case is significant.
NameLength5
[Input] Length of *FKSchemaName, in characters.
FKTableName
[Input] Foreign key table name. FKTableName cannot contain a string search pattern.
If the SQL_ATTR_METADATA_ID statement attribute is set to SQL_TRUE, FKTableName is treated as an identifier and its case is not significant. If it is SQL_FALSE, FKTableName is an ordinary argument; it is treated literally, and its case is significant.
NameLength6
[Input] Length of *FKTableName, in characters.
Returns
SQL_SUCCESS, SQL_SUCCESS_WITH_INFO, SQL_STILL_EXECUTING, SQL_ERROR, or SQL_INVALID_HANDLE.
Actual Odbc Driver
Diagnostics
When SQLForeignKeys returns SQL_ERROR or SQL_SUCCESS_WITH_INFO, an associated SQLSTATE value can be obtained by calling SQLGetDiagRec with a HandleType of SQL_HANDLE_STMT and a Handle of StatementHandle. The following table lists the SQLSTATE values typically returned by SQLForeignKeys and explains each one in the context of this function; the notation '(DM)' precedes the descriptions of SQLSTATEs returned by the Driver Manager. The return code associated with each SQLSTATE value is SQL_ERROR, unless noted otherwise.
| SQLSTATE | Error | Description |
|---|---|---|
| 01000 | General warning | Driver-specific informational message. (Function returns SQL_SUCCESS_WITH_INFO.) |
| 08S01 | Communication link failure | The communication link between the driver and the data source to which the driver was connected failed before the function completed processing. |
| 24000 | Invalid cursor state | A cursor was open on the StatementHandle, and SQLFetch or SQLFetchScroll had been called. This error is returned by the Driver Manager if SQLFetch or SQLFetchScroll has not returned SQL_NO_DATA, and is returned by the driver if SQLFetch or SQLFetchScroll has returned SQL_NO_DATA. A cursor was open on the StatementHandle, but SQLFetch or SQLFetchScroll had not been called. |
| 40001 | Serialization failure | The transaction was rolled back because of a resource deadlock with another transaction. |
| 40003 | Statement completion unknown | The associated connection failed during the execution of this function, and the state of the transaction cannot be determined. |
| HY000 | General error | An error occurred for which there was no specific SQLSTATE and for which no implementation-specific SQLSTATE was defined. The error message returned by SQLGetDiagRec in the *MessageText buffer describes the error and its cause. |
| HY001 | Memory allocation error | The driver was unable to allocate memory that is required to support execution or completion of the function. |
| HY008 | Operation canceled | Asynchronous processing was enabled for the StatementHandle. The function was called, and before it completed execution, SQLCancel or SQLCancelHandle was called on the StatementHandle, and then the function was called again on the StatementHandle. The function was called, and before it completed execution, SQLCancel or SQLCancelHandle was called on the StatementHandle from a different thread in a multithread application. |
| HY009 | Invalid use of null pointer | (DM) The arguments PKTableName and FKTableName were both null pointers. The SQL_ATTR_METADATA_ID statement attribute was set to SQL_TRUE, the FKCatalogName or PKCatalogName argument was a null pointer, and the SQL_CATALOG_NAME InfoType returns that catalog names are supported. (DM) The SQL_ATTR_METADATA_ID statement attribute was set to SQL_TRUE, and the FKSchemaName, PKSchemaName, FKTableName, or PKTableName argument was a null pointer. |
| HY010 | Function sequence error | (DM) An asynchronously executing function was called for the connection handle that is associated with the StatementHandle. This asynchronous function was still executing when the SQLForeignKeys function was called. (DM) SQLExecute, SQLExecDirect, or SQLMoreResults was called for the StatementHandle and returned SQL_PARAM_DATA_AVAILABLE. This function was called before data was retrieved for all streamed parameters. (DM) An asynchronously executing function (not this one) was called for the StatementHandle and was still executing when this function was called. (DM) SQLExecute, SQLExecDirect, SQLBulkOperations, or SQLSetPos was called for the StatementHandle and returned SQL_NEED_DATA. This function was called before data was sent for all) |
| HY117 | Connection is suspended due to unknown transaction state. Only disconnect and read-only functions are allowed. | (DM) For more information about suspended state, see SQLEndTran Function. |
| HYC00 | Optional feature not implemented | A catalog name was specified, and the driver or data source does not support catalogs. A schema name was specified, and the driver or data source does not support schemas. |
| The combination of the current settings of the SQL_ATTR_CONCURRENCY and SQL_ATTR_CURSOR_TYPE statement attributes was not supported by the driver or data source. The SQL_ATTR_USE_BOOKMARKS statement attribute was set to SQL_UB_VARIABLE, and the SQL_ATTR_CURSOR_TYPE statement attribute was set to a cursor type for which the driver does not support bookmarks. | ||
| HYT00 | Timeout expired | The query timeout period expired before the data source returned the result set. The timeout period is set through SQLSetStmtAttr, SQL_ATTR_QUERY_TIMEOUT. |
| HYT01 | Connection timeout expired | The connection timeout period expired before the data source responded to the request. The connection timeout period is set through SQLSetConnectAttr, SQL_ATTR_CONNECTION_TIMEOUT. |
| IM001 | Driver does not support this function | (DM) The driver associated with the StatementHandle does not support the function. |
| IM017 | Polling is disabled in asynchronous notification mode | Whenever the notification model is used, polling is disabled. |
| IM018 | SQLCompleteAsync has not been called to complete the previous asynchronous operation on this handle. | If the previous function call on the handle returns SQL_STILL_EXECUTING and if notification mode is enabled, SQLCompleteAsync must be called on the handle to do post-processing and complete the operation. |
Odbc Driver Install
For information about how the information returned by this function might be used, see Uses of Catalog Data.
If *PKTableName contains a table name, SQLForeignKeys returns a result set that contains the primary key of the specified table and all the foreign keys that refer to it. The list of foreign keys in other tables does not include foreign keys that point to unique constraints in the specified table.
If *FKTableName contains a table name, SQLForeignKeys returns a result set that contains all the foreign keys in the specified table that point to primary keys in other tables, and the primary keys in the other tables to which they refer. The list of foreign keys in the specified table does not contain foreign keys that refer to unique constraints in other tables.
If both *PKTableName and *FKTableName contain table names, SQLForeignKeys returns the foreign keys in the table specified in *FKTableName that refer to the primary key of the table specified in *PKTableName. This should be one key at most.
Note
For more information about the general use, arguments, and returned data of ODBC catalog functions, see Catalog Functions.
SQLForeignKeys returns results as a standard result set. If the foreign keys associated with a primary key are requested, the result set is ordered by FKTABLE_CAT, FKTABLE_SCHEM, FKTABLE_NAME, and KEY_SEQ. If the primary keys associated with a foreign key are requested, the result set is ordered by PKTABLE_CAT, PKTABLE_SCHEM, PKTABLE_NAME, and KEY_SEQ. The following table lists the columns in the result set.
The lengths of VARCHAR columns are not shown in the table; the actual lengths depend on the data source. To determine the actual lengths of the PKTABLE_CAT or FKTABLE_CAT, PKTABLE_SCHEM or FKTABLE_SCHEM, PKTABLE_NAME or FKTABLE_NAME, and PKCOLUMN_NAME or FKCOLUMN_NAME columns, an application can call SQLGetInfo with the SQL_MAX_CATALOG_NAME_LEN, SQL_MAX_SCHEMA_NAME_LEN, SQL_MAX_TABLE_NAME_LEN, and SQL_MAX_COLUMN_NAME_LEN options.
The following columns have been renamed for ODBC 3*.x.* The column name changes do not affect backward compatibility because applications bind by column number.
| ODBC 2.0 column | ODBC 3*.x* column |
|---|---|
| PKTABLE_QUALIFIER | PKTABLE_CAT |
| PKTABLE_OWNER | PKTABLE_SCHEM |
| FKTABLE_QUALIFIER | FK_TABLE_CAT |
| FKTABLE_OWNER | FKTABLE_SCHEM |
The following table lists the columns in the result set. Additional columns beyond column 14 (REMARKS) can be defined by the driver. An application should gain access to driver-specific columns by counting down from the end of the result set instead of specifying an explicit ordinal position. For more information, see Data Returned by Catalog Functions.
Odbc Driver Microsoft
| Column name | Column number | Data type | Comments |
|---|---|---|---|
| PKTABLE_CAT (ODBC 1.0) | 1 | Varchar | Primary key table catalog name; NULL if not applicable to the data source. If a driver supports catalogs for some tables but not for others, such as when the driver retrieves data from different DBMSs, it returns an empty string (') for those tables that do not have catalogs. |
| PKTABLE_SCHEM (ODBC 1.0) | 2 | Varchar | Primary key table schema name; NULL if not applicable to the data source. If a driver supports schemas for some tables but not for others, such as when the driver retrieves data from different DBMSs, it returns an empty string (') for those tables that do not have schemas. |
| PKTABLE_NAME (ODBC 1.0) | 3 | Varchar not NULL | Primary key table name. |
| PKCOLUMN_NAME (ODBC 1.0) | 4 | Varchar not NULL | Primary key column name. The driver returns an empty string for a column that does not have a name. |
| FKTABLE_CAT (ODBC 1.0) | 5 | Varchar | Foreign key table catalog name; NULL if not applicable to the data source. If a driver supports catalogs for some tables but not for others, such as when the driver retrieves data from different DBMSs, it returns an empty string (') for those tables that do not have catalogs. |
| FKTABLE_SCHEM (ODBC 1.0) | 6 | Varchar | Foreign key table schema name; NULL if not applicable to the data source. If a driver supports schemas for some tables but not for others, such as when the driver retrieves data from different DBMSs, it returns an empty string (') for those tables that do not have schemas. |
| FKTABLE_NAME (ODBC 1.0) | 7 | Varchar not NULL | Foreign key table name. |
| FKCOLUMN_NAME (ODBC 1.0) | 8 | Varchar not NULL | Foreign key column name. The driver returns an empty string for a column that does not have a name. |
| KEY_SEQ (ODBC 1.0) | 9 | Smallint not NULL | Column sequence number in key (starting with 1). |
| UPDATE_RULE (ODBC 1.0) | 10 | Smallint | Action to be applied to the foreign key when the SQL operation is UPDATE. Can have one of the following values. (The referenced table is the table that has the primary key; the referencing table is the table that has the foreign key.) SQL_CASCADE: When the primary key of the referenced table is updated, the foreign key of the referencing table is also updated. SQL_NO_ACTION: If an update of the primary key of the referenced table would cause a 'dangling reference' in the referencing table (that is, rows in the referencing table would have no counterparts in the referenced table), the update is rejected. If an update of the foreign key of the referencing table would introduce a value that does not exist as a value of the primary key of the referenced table, the update is rejected. (This action is the same as the SQL_RESTRICT action in ODBC 2*.x*.) SQL_SET_NULL: When one or more rows in the referenced table are updated in such a way that one or more components of the primary key are changed, the components of the foreign key in the referencing table that correspond to the changed components of the primary key are set to NULL in all matching rows of the referencing table. SQL_SET_DEFAULT: When one or more rows in the referenced table are updated in such a way that one or more components of the primary key are changed, the components of the foreign key in the referencing table that correspond to the changed components of the primary key are set to the applicable default values in all matching rows of the referencing table. NULL if not applicable to the data source. |
| DELETE_RULE (ODBC 1.0) | 11 | Smallint | Action to be applied to the foreign key when the SQL operation is DELETE. Can have one of the following values. (The referenced table is the table that has the primary key; the referencing table is the table that has the foreign key.) SQL_CASCADE: When a row in the referenced table is deleted, all the matching rows in the referencing tables are also deleted. SQL_NO_ACTION: If a delete of a row in the referenced table would cause a 'dangling reference' in the referencing table (that is, rows in the referencing table would have no counterparts in the referenced table), the update is rejected. (This action is the same as the SQL_RESTRICT action in ODBC 2*.x*.) SQL_SET_NULL: When one or more rows in the referenced table are deleted, each component of the foreign key of the referencing table is set to NULL in all matching rows of the referencing table. SQL_SET_DEFAULT: When one or more rows in the referenced table are deleted, each component of the foreign key of the referencing table is set to the applicable default in all matching rows of the referencing table. NULL if not applicable to the data source. |
| FK_NAME (ODBC 2.0) | 12 | Varchar | Foreign key name. NULL if not applicable to the data source. |
| PK_NAME (ODBC 2.0) | 13 | Varchar | Primary key name. NULL if not applicable to the data source. |
| DEFERRABILITY (ODBC 3.0) | 14 | Smallint | SQL_INITIALLY_DEFERRED, SQL_INITIALLY_IMMEDIATE, SQL_NOT_DEFERRABLE. |
Code Example
As illustrated in the following table, this example uses three tables, named ORDERS, LINES, and CUSTOMERS.
| ORDERS | LINES | CUSTOMERS |
|---|---|---|
| ORDERID | ORDERID | CUSTID |
| CUSTID | LINES | NAME |
| OPENDATE | PARTID | ADDRESS |
| SALESPERSON | QUANTITY | PHONE |
| STATUS |
In the ORDERS table, CUSTID identifies the customer to whom the sale has been made. It is a foreign key that refers to CUSTID in the CUSTOMERS table.
In the LINES table, ORDERID identifies the sales order with which the line item is associated. It is a foreign key that refers to ORDERID in the ORDERS table.
This example calls SQLPrimaryKeys to get the primary key of the ORDERS table. The result set will have one row; the significant columns are shown in the following table.
| TABLE_NAME | COLUMN_NAME | KEY_SEQ |
|---|---|---|
| ORDERS | ORDERID | 1 |
Next, the example calls SQLForeignKeys to get the foreign keys in other tables that reference the primary key of the ORDERS table. The result set will have one row; the significant columns are shown in the following table.
| PKTABLE_NAME | PKCOLUMN_NAME | FKTABLE_NAME | FKCOLUMN_NAME | KEY_SEQ |
|---|---|---|---|---|
| ORDERS | CUSTID | LINES | CUSTID | 1 |
Finally, the example calls SQLForeignKeys to get the foreign keys in the ORDERS table that refer to the primary keys of other tables. The result set will have one row; the significant columns are shown in the following table.
| PKTABLE_NAME | PKCOLUMN_NAME | FKTABLE_NAME | FKCOLUMN_NAME | KEY_SEQ |
|---|---|---|---|---|
| CUSTOMERS | CUSTID | ORDERS | CUSTID | 1 |
Driver Update Free License Key
Related Functions
| For information about | See |
|---|---|
| Binding a buffer to a column in a result set | SQLBindCol Function |
| Canceling statement processing | SQLCancel Function |
| Fetching a single row or a block of data in a forward-only direction | SQLFetch Function |
| Fetching a block of data or scrolling through a result set | SQLFetchScroll Function |
| Returning the columns of a primary key | SQLPrimaryKeys Function |
| Returning table statistics and indexes | SQLStatistics Function |
